Système de sonorisation compacte Combo 150 W
OMNITRONIC COMBO-75 Active PA system

L'article n'est plus disponible.

Réf. 11038897

Caractéristiques

Système de sonorisation compacte Combo 150 W

Portable PA system for mobile use, ideal for rental companies
Two 150 W speakers
Low-noise 4-channel mic/line mixer and amplifier integrated into a wooden housing with black plastic cover, handle and speaker-flange for installation on a speaker-stand or wall-mounting
Amplifier output power 2 x 75 W RMS / 4 ohms
4 bal. mono input channels (XLR and 6.3 mm jack) with gain control, 2-band EQ and digital reverb
1 adjustable line input (stereo RCA) e.g. CD and MP3 players or for multimedia applications from PC and laptop
Adjustable effect way for controlling external effect units (aux send/return)
Master section with level control, 2-band EQ and reverb control
2 systems can be interconnected for stereo operation

Données techniques

Alimentation électrique:	115/230 V CA, 50/60 Hz
Puissance totale de raccordement:	300,00 W
Plage de fréquence:	30 - 20000 Hz
Dimension:	Largeur : 47,5 cm Profondeur : 31,5 cm Hauteur : 32,5 cm
Poids:	17,70 kg
Mixer unit:
Dimensions:	480 x 255 x 135 mm
Inputs:	4 x mono mic/line (XLR/6.3 mm jack, bal.)
	1 x line (stereo RCA)
	1 x aux return (6.3 mm jack, bal.)
Outputs:	1 x aux send (6.3 mm jack, bal.)
	2 x speaker out (Speaker)
Amplifier unit:
Nominal power output:	2 x 75 W RMS / 4 ohms
Maximum power output:	2 x 150 W / 4 ohms
Distortion:	0.85 %
S/N ratio:	>90 dB
Loudspeakers:
Rated power:	100 W RMS
Program power:	150 W
Components:	25 cm woofer (10"), 2 cm horn (0.8")
Sensitivity:	93 dB
Impedance:	8 ohms
Dimensions:	530 x 370 x 277 mm

Unités de conditionnement

UC	EAN	Poids	Dimension
1	4026397425611	18,90 kg	61cm x 30cm x 61,5cm
1	4026397431605	6,75 kg	47cm x 28,5cm x 18,5cm
