High performance amplifier 2 x 700 W/4 ohms
PSSO HP-1400 Amplifier

High performance amplifier 2 x 700 W/4 ohms-MainBild

High performance amplifier 2 x 700 W/4 ohms-Bild-1

High performance amplifier 2 x 700 W/4 ohms

PSSO HP-1400 Amplifier

L'article n'est plus disponible.

Découvrez les alternatives:

OMNITRONIC Amplificateur XPA-1800

Alternative intéressante à découvrir absolument !

Le stock suffit pour env. 12 semaines.

469,00 €

Réf. 10451650

Imprimer l'article

Étiquette de l'article

Vous trouverez ici les modes d'emploi et les téléchargements pour
PSSO HP-1400 Amplifier

No-frills power packs,
housed in modern class-H technology. The HP-series combines high impulse stability and convincing power reserves with moderate weight, coupled with steadfast operational reliability. For this, high quality components and an extensive packet of protective circuits are responsible.

Caractéristiques

High performance amplifier 2 x 700 W/4 ohms

Class H technology
Power supply with softstart
High impulse stability
Stable metal housing
Plain design with aluminum front panel
Rack installation with 2 units
Complete protection set against overheat, overload, short-circuit, DC, softstart
3 operating modes can be selected (stereo, parallel or bridged)
Electronically balanced inputs via XLR/Jack mounting sockets
Outputs via lockable Speaker-plugs
Operation mode visible via LED display for Signal, Protect and Clip
Calibrated input controls for exact level control, power switch
Ground Lift switch against humming
Bridged switch for bridging
30 Hz Low Cut on the rear panel
Combines superior sound quality with highest reliabilty at significant lower weight
Stable permanent power for all models
Reliable power amp for a wide range of applications

Données techniques

Alimentation électrique:	230 V AC, 50 Hz
Puissance totale de raccordement:	740,00 W
Puissance de sortie:	Max. 1400 W; 400 W RMS (8 Ohm)
Plage de fréquence:	20 - 20000 Hz
Dimension:	Largeur : 48,3 cm Profondeur : 45,6 cm Hauteur : 8,9 cm
Poids:	21,85 kg
Power output (RMS):
Stereo 4 ohms	2 x 700 W
Stereo 8 ohms	2 x 400 W
8 ohms bridged	1 x 1400 W
Signal-to-noise ratio:	>88 dB
Total harmonic distortion:	0.1 %
Damping factor:	450
Voltage gain:	34.3 dB
Slew rate:	30 V/µsec.
Crosstalk:	72 dB
Input sensitivity:	0.77/1/1.4 V
Input impedance:	10/20 kohms (bal./unbal.)
Input connectors:	2 x XLR mounting socket
Output connectors:	2 x Speaker (stereo), 1 x binding post (bridge)
Protection:	Overheat, overload, short-circuit, DC, softstart
Cooling:	2 fans
Controls:	Power switch, input attenuators, mode switch (stereo/parallel/bridged), ground lift
Indicators:	Signal, Clip, Protect, Power
Construction:	Steel chassis, aluminum front panel
	Rack installation with 2 U
