OSRAM HMI 575/GS 95V/575W SFc-10 1000h

Name: OSRAM HMI 575/GS 95V/575W SFc-10 1000h
Brand: OSRAM
SKU: 89301010
Price: 99.00 EUR
Availability: InStock

HMI / MSR / HMP / OMI lamps

OSRAM HMI 575/GS 95V/575W SFc-10 1000h

Stock for approx. 12 wk(s)

99,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 89301010

Print product

Product badge

Here you find the manual and downloads for
OSRAM HMI 575/GS 95V/575W SFc-10 1000h

Basics:
GS=Gap Short (shortened electrode space)
DE=Double Ended (double-sided lamp with threaded pin)
SE=Single Ended (one-sided lamp)
PAR=Lamp built in a parabolic reflector
HMP=Due to their special filling and to their electrode system, HMP-lamps cannot only be "dimmed", but also be "boosted", i. e. be operated beyond their rated power. During this, the light technical characteristics, such as color temperature, color rendering index and light output are practically constant during "dimming" and "boosting".

Features

HMI / MSR / HMP / OMI lamps

Extremely high light output
Best color rendering
Light output three to four times higher in comparison to filament light
Light is generated via an arc between two electrodes
Spectrum similar to daylight
Constant color temperature and color rendering behaviour over the whole lamp life
Halogen metal evaporation lamps provide a spectrum composed of a lot of lines, in contrast to temperature radiators, as halogen-incandescent lamps
Dimmable
Hot restrike
Very high color rendering index (CRI)
Made in Europe
For further information about this product, please refer to the Data Sheet under "Downloads"

Technical specifications

Operating voltage:	95
Nominal wattage:	575 W
Base:	SFc10
Lamp type:	Metal vapour lamp
Lamp specification:	Dimmable Hot restrike
Color temperature:	6000K
Color rendering index (CRI):	90 Ra
Construction:	Double-sided socket
Burning position:	S180 (universal)
Lamp life:	1000 h
Luminous flux:	49000 lm
Dimensions (LxD):	136x21 mm
Weight:	40 g
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4008321285102	0,13 kg	25,3cm x 9,8cm x 6cm
10	4008321285119	1,46 kg	25,5cm x 21cm x 31cm
