PA power amplifier, 350 W RMS
OMNITRONIC PAP-350 PA Amplifier

Name: OMNITRONIC PAP-350 PA Amplifier
Brand: OMNITRONIC
SKU: 80709810
Price: 479.00 EUR
Availability: OutOfStock

2 U

available in approx. 4 wk(s)

Available alternatives

479,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 80709810

Features

PA power amplifier, 350 W RMS

1 line input (optionally XLR or 6.3 mm jack)
1 feed-through output (optionally XLR or 6.3 mm jack)
Master control
LED indicators for power, level, clip and fault
Load detection and power control
Highly efficient Air flow from front to rear
The device is cooled by temperature-controlled fan
(19") 48.3 cm rack installation 2 U
For application areas such as: Installation; restaurants, bars and hotels; sports centres/gyms

Package contents

Technical specifications

Power supply:	230 V AC, 50 Hz
Output power:	350 W RMS
Power connection:	Fixed power supply cord with safety plug
Frequency range:	80 - 16000 Hz
S/N ratio:	>90 dB line
THD:	<0,5 % at 1 kHz
Cooling:	1 x temperature-controlled fan , Air flow from front to rear
Impedance:	4-16 ohms; Public address systems 100V; Public address systems 70V
Circuitry:	Class AB
Controls:	Softstart; overheat; overload; short-circuit; DC voltage
Status LED:	Signal, power, fault, clip
Connections:	Input: line via 1 x 6.3 mm jack socket (mono) mounting version Input: line via 1 x 3-pin XLR 0,3 V Output: line via 1 x 6.3 mm jack socket (mono) mounting version Output: line via 1 x 3-pin XLR
Housing design:	(19") 48.3 cm rack installation 2 U
Dimensions:	Width: 48,3 cm Depth: 38,5 cm Height: 8,9 cm
Weight:	11,90 kg
