Powerful radial wind machine with DMX/RDM and a circulation of 3000 m³/h
ANTARI AF-5X Effect Fan

Name: ANTARI AF-5X Effect Fan
Brand: ANTARI
SKU: 80208058
Price: 1099.00 EUR
Availability: InStock

Powerful radial wind machine with DMX/RDM and a circulation of 3000 m³/h-MainBild

Powerful radial wind machine with DMX/RDM and a circulation of 3000 m³/h-Bild-1

Powerful radial wind machine with DMX/RDM and a circulation of 3000 m³/h

ANTARI AF-5X Effect Fan

Stock for approx. 12 wk(s)

1.099,00 €

Find a dealer

Due to the dimensions of this article, different shipping conditions apply.

List price excl. 19% VAT
Prices in retail stores may vary.

No. 80208058

Print product

Product badge

Here you find the manual and downloads for
ANTARI AF-5X Effect Fan

The Antari AF-5X is a professional special effects fan with a circulation of 3000 m³/h and DMX/RDM control functionality. Ideally suitable for fog, haze, faze and fazer machines. It has 3 optional wind speeds that can also be controlled manually. Besides, it is equipped with an LED display control panel. The W1 wireless remote control is optionally available. The AF-5X can be used in 2 operating positions (horizontal and 45 degrees vertical).

Features

Powerful radial wind machine with DMX/RDM and a circulation of 3000 m³/h

3 speed modes - from gentle to stormy
Control via wireless remote control (optional); stand-alone; DMX
3 digit 7-segment LED display
Sturdy plastic housing with handle qualified for road use

Package contents

1 x device, 1 x user manual

Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	1600 W
Maximum airflow:	3000 m³/h
DMX channels:	1
DMX input:	1 x 5-pin XLR (M) mounting version
Control:	Wireless remote control (optional); stand-alone; DMX
Housing color:	Black
Display type:	3 digit 7-segment LED display
Dimensions:	Length: 55,8 cm Width: 46,5 cm Height: 57,8 cm
Weight:	18,15 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4710586554038	22,10 kg	66cm x 56cm x 67cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

No spare parts available.

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
