Technical specifications

Power supply:	100-240 V AC, 50/60 Hz 5V DC 1000 mA
Power consumption:	5 W
Power connection:	Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Power output:	Screw plug-in terminal
DMX channels:	Output 512
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Network connection:	Protocol: Art-Net 3 via 2x RJ-45 (F) mounting version
Control:	Art-Net
PC connect:	Via RJ-45 (F) mounting version
Dimensions:	Width: 15.3 cm Depth: 9 cm Height: 3.7 cm
Weight:	0.47 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397543193	0,65 kg	23cm x 19cm x 9cm
12	4026397543209	8,40 kg	61cm x 25,5cm x 38cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Software

Name	Version	Language
70064842-SW-119412-Firmware-V14-en.rar (716 KB)	0.0000	en

All images

Name	Version	Language
70064842-Images-.zip

EUROLITE Art-Net/DMX Node 1

The article is no longer in our assortment.

Check out the alternatives:

No. 70064842

LED controller and Art-Net/DMX converter

Compact LED controller for controlling RGB and RGBA/RGBW LEDs via Art-Net and DMX
Converts standard DMX512 signals and Art-Net data to PWM signals for driving LEDs
For use with the digital LED pixel strip (item 50530200)
Applicable as standard Art-Net/DMX converter for 1 DMX512 universe (512 channels)
DMX input and parallel DMX output for serial connection via XLR connectors
Ethernet port: 2 x RJ45, 10/100 Mbps
Stand-alone operation possible with 16 built-in light programs
2 x 8-digit LCD screen for menu settings
Terminals for connecting the LEDs
Powered via included PSU
Rugged black metal housing
Can transmit up to 512 DMX channels
Control via Art-Net
The device can be connected via RJ-45 (F) mounting version to the PC
