Compact DMX controller for easy application

EUROLITE DMX LED Operator 3 controller

The article is no longer in our assortment.

Item no. 70064503

Print product

Product badge

Here you find the manual and downloads for
EUROLITE DMX LED Operator 3 controller

The EUROLITE DMX LED Operator 3 is a DMX-controller especially designed for the EUROLITE LED-spots with zoom and 6 DMX-channels.
This controller features pre-programmed presets and colours, which can easily be displayed by pressing one button. Save your precious time for programming the individual DMX-channels in order to display this colour or that colour.

Features

Compact DMX controller for easy application

6 control channels only suitable for LED-spots with zoom (Eurolite LED MLZ-56)
Select color mode for choosing single colors
Internal programs
Auto mode for running all programs
Sound-control via built-in microphone
Pause function
Blackout function
Control LEDs display current operating mode
Program Select-fader for selecting the internal programs
Speed-fader for adjusting the program-speed
Strobe-effect with adjustable speed
Designed for standing operation, optional installation is customer's choice
Power supply via enclosed 12 V DC power unit

Technical specifications

Power consumption:	4,00 W
Dimensions:	Width: 22 cm Depth: 14,5 cm Height: 6,5 cm
Power supply:	230 V AC, 50 Hz,
	via 12 V DC, 300 mA power unit included in the delivery
Number of control channels:	6
Sound-control:	via built-in microphone
DMX512 output:	3-pin XLR connector
Dimensions (L x W x H):	220 x 145 x 65 mm
Weight:	1 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397465815	1,14 kg	31cm x 20,5cm x 13cm
4	4026397465822	5,15 kg	44cm x 33,5cm x 29,5cm

Support

Spare parts

Power Supply 12V/500mA

Knob black button LED Operator small
