2-point truss system
ALUTRUSS BISYSTEM PV-23 2-way 135° vertical

Name: ALUTRUSS BISYSTEM PV-23 2-way 135° vertical
Brand: ALUTRUSS
SKU: 60301050
Price: 74.90 EUR
Availability: LimitedAvailability

2-point truss system

ALUTRUSS BISYSTEM PV-23 2-way 135° vertical

only a few items available

74,90 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 60301050

Print product

Product badge

Here you find the manual and downloads for
ALUTRUSS BISYSTEM PV-23 2-way 135° vertical

BISYSTEM 2-point truss system
BISYSTEM is a 2-point truss system made of aluminum. The individual elements are connected via two tube fasteners and two M10 bolts and nuts.

The two main chords are made of 50 mm aluminum tube with 2 mm wall thickness and offer a good relation between strength and weight. The braces have a diameter of 12 mm with 2 mm wall thickness and leave enough space for installing couplers, hooks and clamps.

With 238 mm outer dimensions, BISYSTEM is a relatively compact truss system for higher loads. BISYSTEM is mainly designed for permanent installations in shops, discotheques and theatres.

By using the optional rapid snap connectors, this system can also be used for fair installations and event installations.

Altogether a universal truss system impressing with its wide range of standard system lengths, corners and accessory.

Features

2-point truss system

High-quality aluminum-tubes with 50 mm in diameter
Low weight
Easy installation
Direction vertical
Trusspipe: 50 mm
Made in Europe
For application areas such as: Theater; Trade fair and shop fitting; clubs/dancing school

Package contents

1 x connection set

Technical specifications

Setup:	Easy installation
Trusspipe:	50 mm x 2 mm
Welding technique:	TIG-welding
Welding material:	AlMg 5
Alloy:	AlMgSi 0.5
Color:	Alu colored
Strut diameter x thickness:	12 x 2mm
Weight:	2,35 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397105469	2,40 kg	70,5cm x 38cm x 24cm

Support

Spare parts

No spare parts available.

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
