High-quality winch-stand, maximum load 85 kg, maximum height 400 cm
EUROLITE STT-400/85 Winch Stand TÜV/GS

Name: EUROLITE STT-400/85 Winch Stand TÜV/GS
Brand: EUROLITE
SKU: 59007040
Price: 279.00 EUR
Availability: InStock

High-quality winch-stand, maximum load 85 kg, maximum height 400 cm-MainBild

High-quality winch-stand, maximum load 85 kg, maximum height 400 cm-Bild-1

High-quality winch-stand, maximum load 85 kg, maximum height 400 cm

EUROLITE STT-400/85 Winch Stand TÜV/GS

Stock for approx. 12 wk(s)

279,00 €

Save money: This article is available in a bundle.

Find a dealer

Due to the dimensions of this article, different shipping conditions apply.

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 59007040

Print product

Product badge

Here you find the manual and downloads for
EUROLITE STT-400/85 Winch Stand TÜV/GS

The EUROLITE STT-series are winch-driven stands manufactured under strict TUV monitoring. These stands boast of high quality, exraordinary ruggedness, highest versatility and high stability. The production is monitored by the German TÜV SÜD which means that they comply with the highest safety standards.

The GS mark signals to the buyer, customer, or consumer that the chosen product as well as the user manual and production (process) have been tested by an authorized institution such as TÜV SÜD, with priority being given to aspects of safety. In the meantime, the German GS-mark has been recognized as one of the crucial marks within product safety.

Save money: This article is available in a bundle.

Sets are loaded. Please wait...

Features

High-quality winch-stand, maximum load 85 kg, maximum height 400 cm

1-gear winch for easy lifting of the loads
Automatic braking system
Safety bolt for mechanical locking
Easy handling
Complies with DIN 15560-27 and DIN EN ISO 12100-2
Adjustable height
TÜV Süd certified
For application areas such as: Mobile use

Package contents

1 x user manual

Technical specifications

Maximum carrying capacity:	85 kg
Minimum load:	25 kg
Standard:	DIN 15560-27, DIN EN ISO 12100-2
Height:	Maximum: 400 cm above 3 sections Minimum: 175 cm
Attachment system:	Ø 35mm
Steel rope:	Ø 4 mm
Type (general stands):	Light stand/wind up
Transport dimensions:	1,75 m x 30 cm x 27 cm
Base area:	Ø 1,6 m
Weight:	24,10 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397277890	27,45 kg	183cm x 25cm x 28,5cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

EUROLITE Cable for STT-400/85

EUROLITE Safety-pin STT-400

EUROLITE Winding mechanics complete for STT-400/85

More 3 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/Produktanfrage

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
