Approved safety bond
EUROLITE Steel Rope 1000x4mm black with Thimbles
Installation rope, safety bond, safety
EUROLITE Quick Link Type A-90
Quick link
Package contents
| Secured weight (BGV C1): | Max. 15 kg |
| Strength classification: | 1770 |
| Temperature range: | -40° C - +100° C |
| Weight: | 90 g |
| EUROLITE Steel Rope 1000x4mm black with Thimbles | |
| Maximum load WLL (5-fold): | 175 kg |
| Design of the core: | 6 x 19 FC |
| Strength classification: | 1960 |
| Standard: | DIN EN 12385-4:2008-06, DIN 56927:2009-03 |
| Nominal tensile strenght of rope: | 1770 N/mm² |
| Wire surface: | Zinc-plated |
| Color: | Black |
| Temperature range: | -40° C - +100° C |
| Dimensions: | Length: 1 m Diameter: Ø 4 mm |
| Weight: | 80 g |
| Length weigth: | 0,0554 kg/m |
| EUROLITE Quick Link Type A-90 | |
| Maximum load WLL (10-fold): | 90 kg |
| Standard: | DIN 56927:2009-03, |
| Shape: | A - small opening |
| Material: | Steel, zinc-plated |
| Opening: | 0-5,5 mm |
| Dimensions: | Length: 3,10 cm Width: 4,10 cm Depth: 2,20 cm Diameter: Ø 4 mm |
| Weight: | 10 g |
