Outdoor spotlight (IP65) for stroboscope, ambient and animation effects
EUROLITE LED IP PIX Strobe RGB CW+WW

Name: EUROLITE LED IP PIX Strobe RGB CW+WW
Uploaded: 2022-01-01
Description: Outdoor spotlight (IP65) for stroboscope, ambient and animation effects

Outdoor spotlight (IP65) for stroboscope, ambient and animation effects-MainBild

Outdoor spotlight (IP65) for stroboscope, ambient and animation effects-Bild-1

120°

Outdoor spotlight (IP65) for stroboscope, ambient and animation effects

EUROLITE LED IP PIX Strobe RGB CW+WW

available in approx. 2 wk(s)

199,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 52200940

Print product

Product badge

Here you find the manual and downloads for
EUROLITE LED IP PIX Strobe RGB CW+WW

Features

Outdoor spotlight (IP65) for stroboscope, ambient and animation effects

240 powerful LEDs 0,5 W SMD 5050 3in1 TCL RGB
8 segments controlled separately
40 powerful LEDs 1 W SMD 3030 2in1 BCL CW/WW
4 segments controlled separately
Compact and bright
Background color adjustable; Dimmer electronic; color blend stepless; program speed adjustable; program selection adjustable; running light adjustable
Variable color temperature 3200 K - 6600 K
20 integrated show programs
Show programs for white and colored LEDs on separate DMX channels
Preprogrammed in Colorchief; Light Captain
Control via stand-alone; sound to light via microphone; master/slave function; DMX
Flicker-free
With a beam angle of 120°
With mounting bracket
OLED display
The device is cooled by passive convection cooling
Suitable for outdoor use IP65
With pressure compensation membrane
Mains input and output for power linking up to 8 units
Application possibility: Standing; suspended
Built with SEETRONIC connector
For application areas such as: Clubs/dancing school; installation; stage; mobile djs / entertainer; architecture
Silent operation

Package contents

1 x device, 1 x user manual, 1 x power cord

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	135 W
IP classification:	IP65
Protection class:	Protection class I
Power connection:	Mains input via IP T-Con (M) mounting version power supply cord with safety plug
Power output:	IP T-Con (F) mounting version
Fuse:	T 5 A fuse fix in power supply
Lamp type:	LED lamp
LED type:	240 x 0,5 W SMD 5050 3in1 TCL RGB 40 x 1 W SMD 3030 2in1 BCL CW/WW
Flash rate:	0 - 20 Hz
DMX channels:	6; 10; 18; 24; 25; 32
DMX input:	1 x 3-pin XLR (M) mounting version IP
DMX output:	1 x 3-pin XLR (F) mounting version IP
Cooling:	Passive convection cooling
Control:	Stand-alone; sound to light via microphone; master/slave function; DMX
Preprogrammed in:	Colorchief; Colorchief; Light Captain
Projection:	Flicker-free
Beam angle:	120°
Beam angle (1/2 peak):	120°
Color temperature:	3200K - 6600K adjustable
Housing color:	Black
Attachment system:	Mounting bracket
Display type:	OLED display
Use of brands:	Built with SEETRONIC connector
Dimensions:	Length: 38 cm Depth: 11 cm Height: 14,5 cm
Weight:	3,30 kg
Noise classification:	Class 0 (no noise at all)
Mounting bracket
Diameter mounting holes:	3 x Ø13mm
Material:	Metal, 3 mm
Power cord
Cable construction:	3 x 1,5 mm² H07RN-F
Cable length:	Approx. 1,2 m
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397727661	3,68 kg	41,5cm x 19,5cm x 16cm
4	4026397728729	15,50 kg	44cm x 41cm x 36cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Pcb (Display/Control) LED IP PIX Strobe (LED-FS-PAR-M-V2.1)

Pcb (LED) LED IP PIX Strobe (LED-50240-3040-V2.0)

Pcb (power supply) 33V/5A LED IP PIX Strobe (XZY-U180)

More 2 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
