Strobe with bright SMD 5050 LEDs and DMX
EUROLITE LED Strobe SMD PRO 132x5050 DMX

The article is no longer in our assortment.

Item no. 52200910

Features

Strobe with bright SMD 5050 LEDs and DMX

DMX-controlled operation or stand-alone operation with Master/Slave function possible
DMX512 control possible via any commercial DMX controller (occupies 2 channels)
Sound control via built-in microphone
Microphone sensitivity adjustable via control board
Comfortable addressing and setting via control board with LED display and four operating buttons
Brightness and flash-rate steplessly adjustable
Compact housing with mounting bracket and fixation screws
Equipped with 132 powerful SMD 5050 LEDs
Switch-mode power supply for operation between 100 and 240 volts
Ready for connection via included IEC power cord with safety power plug
Control via stand-alone; DMX
Preprogrammed in Light´J; LED PC-Control 512

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	25 W
Lamp type:	LED lamp
Control:	Stand-alone; DMX
Preprogrammed in:	Light´J; LED PC-Control 512
Dimensions:	Width: 34,6 cm Depth: 18,5 cm Height: 8,9 cm
Weight:	2,28 kg
DMX channels:	2
DMX connection:	3-pin XLR
Sound-control:	via built-in microphone
LED type:	SMD 5050, white
LED number:	132
Color temperature:	6005 K
Dimensions:	89x346x185 mm
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397578935	2,66 kg	40cm x 24cm x 18cm
8	4026397578942	22,30 kg	81cm x 38cm x 46cm
