Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	50 W
IP classification:	IP65
Power connection:	Mains input via IP T-Con (M) power supply cord with safety plug
Power output:	IP T-Con (F)
Lamp type:	LED lamp
LED type:	16 x 8 W high-power 4in1 QCL RGBW (homogenous color mix)
Flash rate:	0.8 - 20 Hz
DMX channels:	3; 4; 5; 6; 9
DMX input:	3-pin XLR (M) IP
DMX output:	3-pin XLR (F) IP
Cooling:	Passive convection cooling
Control:	DMX; master/slave function; stand-alone; IR remote control
Fixtures available for:	Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Projection:	Flicker-free
PWM frequency:	4000 Hz
Beam angle:	20°
Beam angle (1/2 peak):	20°
Beam angle (1/10 peak):	35°
Housing color:	Black
Attachment system:	2x mounting bracket
Display type:	4 digit 7-segment LED display
Dimensions:	Length: 106.50 cm Depth: 10.00 cm Height: 12.65 cm
Weight:	5.95 kg
Noise classification:	Class 0 (no noise at all)
Photobiological safety:	Risk Group 0
Remote control
Battery:	1 x button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397680959	6,50 kg	105cm x 13,5cm x 17,5cm
2	4026397681550	13,80 kg	106,5cm x 28,5cm x 21cm

Spare parts

LED QCL 8W RGBW (TX-BRWG2B140)

Washer (Plastic, black)

Pcb (Power supply) 28V/2.68A LED IP T-Bar 16 QCL (HS-U75S28(LED))

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Dimensional drawing

Name	Version	Language
51914107-Dimensions-162452-1.0000-51914107dimensionspdf-de.pdf (46 KB)	1.0000	de

Support

Name	Version	Language
51914107-Support-136618-Fixture-fuer-Colorchief-V2X-de.zip (223 B)	0.0000	de

All images

Name	Version	Language
51914107-Images-.zip

Video link

https://www.youtube-nocookie.com/embed/St04qfc_xlk

EUROLITE LED IP T-Bar 16 QCL Bar

Name: EUROLITE LED IP T-Bar 16 QCL Bar
Uploaded: 2022-01-01
Description: Weather-proof (IP65) bar with RGBW color mixing, incl. IR remote control

Weather-proof (IP65) bar with RGBW color mixing, incl. IR remote control-MainBild

Weather-proof (IP65) bar with RGBW color mixing, incl. IR remote control-Bild-1

EUROLITE LED IP T-Bar 16 QCL Bar

Stock for approx. 11 wk(s)

299,00 €

Find a dealer

Stock for approx. 11 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51914107

20°

Weather-proof (IP65) bar with RGBW color mixing, incl. IR remote control

16 LEDs 8 W high-power 4in1 QCL RGBW (homogenous color mix)
Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic
Strobe effect
Direct color selection for 19 preset colors
The device is cooled by passive convection cooling
Control via DMX; master/slave function; stand-alone; IR remote control
Fixtures available for Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Flicker-free
With a beam angle of 20°
With mounting bracket
4 digit 7-segment LED display
Mains input and output for power linking up to 8 units
Suitable for outdoor use
For application areas such as: Architecture; stage; clubs/dancing school; wedding/gala/events; restaurants, bars and hotels; theater; rental
Silent operation
Application possibility: Suspended; wall mounting
