Electric firing unit for confetti and streamers
TCM FX E-Shot

Name: TCM FX E-Shot
Uploaded: 2022-01-01
Description: Electric firing unit for confetti and streamers

Electric firing unit for confetti and streamers-MainBild

Electric firing unit for confetti and streamers-Bild-1

Electric firing unit for confetti and streamers

TCM FX E-Shot

Stock for approx. 12 wk(s)

219,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 51708000

Print product

Product badge

Here you find the manual and downloads for
TCM FX E-Shot

The Confettimaker's E-Shot is an easy-to-use electric confetti shooter. The shooter is designed to fire prefilled single-use electric cannons, which are available in 40 cm and 80 cm length. Confetti or streamers in various colours, even UV and metallic colors are available. The cannons contain a pressurized nitrogen cartridge which launches confetti up to 12 meters and streamers even up to 20 meters wide.

The E-Shot will be activated by a 230V power source and can therefore be operated very easy by a 230V power switch like the The Confettimaker FX-Control (51708250). If you like to operate by DMX you can use a The Confettimaker DMX Switchpack (51708260, 51708265) in combination with a any DMX controller.

Features

Electric firing unit for confetti and streamers

The electric shooter can be used for confetti or streamer cannons
Suitable for electric cannons with 50and 80 cm length
The shooting angle can be adjusted steplessly
Activated by a 230V power source
Output distance: Approx. 20 m
Control via plug and play
Made in Europe
For application areas such as: Carnival

Package contents

1 x device, 1 x user manual

Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	100 W
Power connection:	Mains input via PowerCON (blue), mounting version power supply cord with safety plug
Power output:	1 x PowerCON (gray), mounting version 1 x special connector recessed mounting
Output distance:	Approx. 20 m
Control:	Plug and play
Housing color:	Black
Dimensions:	Width: 12 cm Depth: 13 cm Height: 16 cm
Weight:	1,78 kg

Packaging units

PU	EAN	Weight	Dimensions
1	8719699077058	1,86 kg	18cm x 16cm x 13cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Connector E-Shot

Downloads

Loading the documents. Please wait...

Manufacturer information

The Confetti Maker BV
Florijnstraat 101
NL-2988CL Ridderkerk

+31 10 2541111
info@theconfettimaker.com
www.theconfettimaker.com

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
