Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	3000 W
Protection class:	Protection class I
Power connection:	Mains input via PowerCON (blue), mounting version power supply cord with safety plug (provided)
Warm-up time:	Approx. 12 min
Output distance:	Approx. 7 m
Tank capacity:	6.0 l water-based fluid removable tank
Fluid consumption:	Approx. 190 ml/min
DMX channels:	1
DMX input:	1 x 3-pin XLR (M) mounting version 1 x 5-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version 1 x 5-pin XLR (F) mounting version
Control:	Stand-alone; W-DMX by wireless solution; DMX; wireless remote control
Range:	Range up to 50m
Carrier frequency:	433.920 MHz
Housing color:	Grey
Display type:	Monochrome LCD display
Controls:	Low fluid
Use of brands:	Built with NEUTRIK connector
Color:	Grey
Dimensions:	Width: 27.8 cm Depth: 58.1 cm Height: 18.6 cm
Weight:	19.45 kg
Remote control
Battery:	1 x 12 V LR27 alkaline manganese built-in

Packaging units

PU	EAN	Weight	Dimensions
1	4719850651787	21,30 kg	70cm x 37,5cm x 35cm
1	4026397515190	21,00 kg	69cm x 37,5cm x 35cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
51702712-Images-.zip

ANTARI W-530D Fogger

The article is no longer in our assortment.

No. 51702712

3000 watt fogger with DMX

Rugged metal housing
Wireless DMX receiver, 2.4 GHz
Adaptive frequency hopping ensures interference-free operation in the 2.4 GHz band
Efficient heat exchanger provides for 20 % more fog than comparable fog machines and ensures low fluid consumption
Adjustable timer with interval, duration and output volume
Continuous output with adjustable snow volume or manual activation with maximum snow volume
The transmitter allows simultaneous control of an unlimited number of machines
Output distance: Approx. 7 m
Big tank capacity
Operates on water-based fluid
Removable tank
Control via stand-alone; W-DMX by wireless solution; DMX; wireless remote control
Operating range up to 50m
Monochrome LCD display
Built with NEUTRIK connector
For application areas such as: Mobile use; clubs/dancing school; stage
