Controller with DMX interface for the RGB LED neon tube (item 50499801)
EUROLITE Controller PRO with DMX for LED Neon Flex 230V Slim RGB

Name: EUROLITE Controller PRO with DMX for LED Neon Flex 230V Slim RGB
Brand: EUROLITE
SKU: 50499811
Price: 69.90 EUR
Availability: InStock

Controller with DMX interface for the RGB LED neon tube (item 50499801)-MainBild

Controller with DMX interface for the RGB LED neon tube (item 50499801)-Bild-1

Controller with DMX interface for the RGB LED neon tube (item 50499801)

EUROLITE Controller PRO with DMX for LED Neon Flex 230V Slim RGB

Stock for approx. 3 wk(s)

69,90 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 50499811

Print product

Product badge

Here you find the manual and downloads for
EUROLITE Controller PRO with DMX for LED Neon Flex 230V Slim RGB

Features

Controller with DMX interface for the RGB LED neon tube (item 50499801)

Compact controller for the slim LED neon tube (item 50499801) via DMX
3 separate control channels for individual color mixing of red, green and blue LEDs
4-pin cable for connecting the LED neon tube
Rugged black metal housing
Integrated show programs
Control via stand-alone; DMX; sound to light via microphone

Package contents

1 x device, 1 x power cord, 1 x adapter, 1 x tube, 1 x user manual

Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	Max. 1380 W Max. 460 W per channal
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug included
DMX channels:	6
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Control:	Stand-alone; DMX; sound to light via microphone
Housing color:	Black matte
Diameter mounting holes:	6 x Ø5mm
Dimensions:	Width: 22,5 cm Depth: 10 cm Height: 5 cm
Weight:	1,17 kg
Power cord
Cable construction:	3 x 1,5 mm² H05VV-F
Cable length:	Approx. 1,2 m

Packaging units

PU	EAN	Weight	Dimensions
1	4026397618709	1,35 kg	26cm x 17cm x 10cm
10	4026397622720	15,10 kg	61cm x 28cm x 36cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

DIP-switsches 10-pin piano

Transistor IRF 740

Optoisolator 4N35

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/Produktanfrage

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
