Quick link
EUROLITE Quick Link Type B-90

Name: EUROLITE Quick Link Type B-90
Brand: EUROLITE
SKU: 50301655
Price: 3.50 EUR
Availability: InStock

4 mm

Quick link

EUROLITE Quick Link Type B-90

Stock for approx. 12 wk(s)

3,50 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 50301655

Print product

Product badge

EUROLITE quick links
The EUROLITE quick links comply with the current regulation of the German professional insurance association as summed up in BGI 810-3:2007-03 Loads above persons. The quick links are constructed in accordance with the German standard DIN 56927:2009-03.
The quick links are manufactured by a renowned German supplier and are tested by the LGA, an independent and accredited testing institute. The breaking load testified by the LGA is documented in the test report according to DIN EN 10204 required by the German professional insurance association.
Clearly, every user can secure loads above persons with these quick links in all areas where the BGV C1 is required.

Features

Quick link

Complies with DIN 56927:2009-03

Technical specifications

Maximum load WLL (10-fold):	90 kg
Standard:	DIN 56927:2009-03,
Shape:	B - big opening
Material:	Steel, zinc-plated
Opening:	0-11,5 mm
Dimensions:	Length: 4,50 cm Diameter: Ø 4 mm
Weight:	20 g

Packaging units

PU	EAN	Weight	Dimensions
1	4026397494990	0,02 kg	5,5cm x 2,5cm x 1cm
100	4026397495003	1,63 kg	18cm x 8cm x 9cm

Support

Spare parts

No spare parts available.

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/Produktanfrage

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
