EUROLITE LED KLS Scan Next FX Compact Light Set

Name: EUROLITE LED KLS Scan Next FX Compact Light Set
Uploaded: 2022-01-01
Description: Compact bar with derby, spots, scanners, UV effect, QuickDMX port and bag

Compact bar with derby, spots, scanners, UV effect, QuickDMX port and bag-MainBild

Compact bar with derby, spots, scanners, UV effect, QuickDMX port and bag-Bild-1

spotlight

light effect

bar

moving light

15° spotlight

Compact bar with derby, spots, scanners, UV effect, QuickDMX port and bag

EUROLITE LED KLS Scan Next FX Compact Light Set

Stock for approx. 12 wk(s)

799,00 €

Save money: This article is available in a bundle.

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 42109897

Print product

Product badge

Here you find the manual and downloads for
EUROLITE LED KLS Scan Next FX Compact Light Set

EUROLITE LED KLS Scan Next FX Compact Light Set cover image

LED KLS Scan NEXT FX by Eurolite

Everything in a compact light set: basic light, effects and scanner

The LED KLS Scan Next FX is equipped with 4 spots for the colored basic lighting, UV LEDs for the popular black light effect and a derby effect for the party atmosphere. But the special feature of this bar is the equipment with two integrated scanners incl. gobo wheel and color wheel. The two scanners are each equipped with a very effective 15-watt LED.

EUROLITE LED KLS Scan Next FX Compact Light Set control

Control via standalone, remote control and foot switch

The control options of the KLS offer something for every user: even without an external controller, 20 different programs can be set that run either automatically or music-controlled. These programs offer well thought-out, carefully selected shows in terms of color. The various programs can be called up and colorful moods created via the infrared remote control supplied. Control via an optional footswitch is also possible.

EUROLITE LED KLS Scan Next FX Compact Light Set example of use image 1

EUROLITE LED KLS Scan Next FX Compact Light Set

Different DMX modes

There are ten different DMX modes: In the smallest mode with three channels, the automatic and music-controlled programs can be called up and switched. The largest mode with 39 channels allows full control of each fixture, the derby and the scanners. In some modes, the two scanners are controlled together. In the menu, it is then possible to set that one or both axes of movement should be inverted, i.e. mirrored. This facilitates the control and results in a coherent picture.

EUROLITE LED KLS Scan Next FX Compact Light Set connections

Wireless DMX

The KLS has a USB socket for QuickDMX. An optional DMX wireless adapter can be plugged into this to realize wireless DMX transmission. This works not only from one console to the KLS bars, but also with several KLS units for master-slave operation.

EUROLITE LED KLS Scan Next FX Compact Light Set example of use image 2

Save money: This article is available in a bundle.

Sets are loaded. Please wait...

Features

Compact bar with derby, spots, scanners, UV effect, QuickDMX port and bag

Crossbar with integrated DMX control unit and TV spigot for tripod installation
When fog is used, this effect becomes especially attractive
Positioning within TILT
Color wheel; gobo wheel with static gobos
20 integrated show programs
Control via DMX; IR remote control; sound to light via microphone; stand-alone; master/slave function; wireless footswitch (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
OLED display
For application areas such as: Rental; small rental; wedding/gala/events; mobile use; mobile djs / entertainer
Mains input and output for power linking up to 8 units
Color wheel with 8 dichroic filters plus open
half colors selectable
Preprogrammed in Light Captain; EASY SHOW 2; EASY SHOW 3
Application possibility: Suspended; on stand

spotlight

3 powerful LEDs 7 W high-power 4in1 QCL RGB/WW (homogenous color mix)
4 spots controlled separately
With a beam angle of 15°

light effect

2 powerful LEDs 3 W R/G/B

moving light

1 powerful LED 15 W cold white (CW)

bar

4 powerful LEDs 1 W high-power ultra violet (UV)
LEDs controlled separately

Package contents

1 x device, 1 x user manual, 1 x power cord, 1 x declaration of conformity, 2 x mounting bracket, 1 x remote control, 1 x battery, 1 x bag, 2 x knurled screw, 2 x washer, 1 x terminating plug (power)

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	115 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:	P-Con (gray), mounting version
Fuse:	5 x 20 mm, T 2 A fuse replaceable
Lamp type:	LED lamp
Equipment:	Color wheel; gobo wheel with static gobos
Color generation:	Cold white (CW)
Color generation:	Color wheel with 8 dichroic filters plus open Half colors selectable
DMX channels:	3; 7; 13; 14; 15; 18; 19; 30; 32; 39
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Cooling fan
Control:	DMX; IR remote control; sound to light via microphone; stand-alone; master/slave function; wireless footswitch (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in:	Light Captain; EASY SHOW 2; EASY SHOW 3
Housing color:	Black
Attachment system:	TV spigot Ø 28mm 2x mounting bracket
Display type:	OLED display
Dimensions:	Width: 1,1 m Depth: 15,5 cm Height: 43 cm
Weight:	12,80 kg
Noise classification:	Class 3 (clearly perceptible sounds)
Remote control
Battery:	1 x button cell 3.0 V CR2025 lithium manganese built-in
Bar
LED type:	4 x 1 W high-power ultra violet (UV)
Light effect
LED type:	2 x 3 W R/G/B
Spotlight
LED type:	3 x 7 W high-power 4in1 QCL RGB/WW (homogenous color mix)
Beam angle:	15°
Beam angle (1/2 peak):	15°
Beam angle (1/10 peak):	28°
Illuminance in Lux (lx):	Red (R) 1m: 1022 lx, 3m: 125 lx, 6m: 33 lx Green (G) 1m: 2448 lx, 3m: 285 lx, 6m: 75 lx Blue (B) 1m: 395 lx, 3m: 47 lx, 6m: 13 lx Warm white (WW) 1m: 1892 lx, 3m: 219 lx, 6m: 58 lx All 1m: 4853 lx, 3m: 676 lx, 6m: 175 lx
Moving light
LED type:	1 x 15 W cold white (CW)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397690064	13,80 kg	115cm x 17,5cm x 52cm
