Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM
EUROLITE LED IP PFE-40 CW/WW 25-50°

Name: EUROLITE LED IP PFE-40 CW/WW 25-50°
Uploaded: 2022-01-01
Description: Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM

Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM-MainBild

Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM-Bild-1

25 - 50°

Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM

EUROLITE LED IP PFE-40 CW/WW 25-50°

Stock for approx. 12 wk(s)

699,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

No. 40001706

Print product

Product badge

Here you find the manual and downloads for
EUROLITE LED IP PFE-40 CW/WW 25-50°

Features

Weather-proof spotlight (IP65), 40 W COB LED, variable color temperature, CRI >90, RDM

1 powerful LED 40 W COB (chip-on-board) 2in1 BCL CW/WW (homogenous color mix)
Variable color temperature 2700 K - 6000 K
4 shutter blades
Zoom manual; focus manual
With a beam angle of 25° - 50°
Dimmer electronic; Dimmer speed (step response) adjustable; pulse-width modulation variable
Strobe effect
Control via stand-alone; master/slave function; DMX; RDM
Very high color rendering index (CRI)
With mounting bracket
4 digit 7-segment LED display
Dimmable
Very quiet working noise
Preprogrammed in Light´J; Light Captain
For application areas such as: Installation; stage; theater; rental
Application possibility: Suspended; on stand

Package contents

1 x device, 1 x gobo holder, 1 x filter frame, 1 x user manual, 1 x power cord, 1 x adapter cable, 1 x safety bond

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	30 W
IP classification:	IP65
Protection class:	Protection class I
Power connection:	Mains input via IP T-Con (M) mounting version power supply cord with safety plug (provided)
Lamp type:	LED lamp
Lamp specification:	Dimmable
LED type:	1 x 40 W COB (chip-on-board) 2in1 BCL CW/WW (homogenous color mix)
Equipment:	Zoom manual; focus manual
DMX channels:	1; 2; 3; 6
DMX input:	1 x 3-pin XLR (M) mounting version IP
Control:	Stand-alone; master/slave function; DMX; RDM
Preprogrammed in:	Light´J; Light Captain
Beam angle:	25° - 50°
Beam angle (1/2 peak):	25 - 50°
Beam angle (1/10 peak):	25 - 50°
Color temperature:	2700K - 6000K adjustable
Color rendering index (CRI):	92 Ra
Housing color:	Black
Attachment system:	Mounting bracket
Display type:	4 digit 7-segment LED display
Dimensions:	Length: 34,5 cm Width: 15,5 cm Height: 28,5 cm
Weight:	3,95 kg
Noise classification:	Class 1 (very slight noise, suitable for noise-sensitive environments)
Gobo holder
Gobos:	Outside diameter 37,5mm Image diameter 25mm
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397718676	4,50 kg	44cm x 21cm x 23cm
4	4026397719215	19,00 kg	46cm x 44cm x 49cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Pcb (Power supply) 41V/1A LED IP PFE-40 (XZY-L41-41)

Pcb (Display) LED IP PFE-40 (HXY-268-MPCB)

Pcb (LED) LED IP PFE-40 (T30)

More 1 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.

Similar products

Loading alternatives. Please wait...
