EUROLITE Set LED CAT-80 Beam Effect + Soft Bag

Stock for approx. 12 wk(s)

349,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

No. 20000988

Set consisting of:

1 x EUROLITE LED CAT-80 Beam Effect

1 x EUROLITE SB-4 Soft Bag L

Features

EUROLITE LED CAT-80 Beam Effect

LED beam effect with cold white 80 W COB LED and gobo wheel

3 different motion axes
Rotating faceted mirror inside
Rotating and swiveling mirror cylinder
Generates countless moving patterns in the room
1 powerful LED 80 W COB (chip-on-board) cold white (CW)
Gobo wheel with static gobos; focus manual
Dimmer electronic
Mirror cylinder effect; strobe effect
Gobo wheel with static gobos, 9 color gobos and open
The device is cooled by cooling fan
Control via stand-alone; master/slave function; sound to light via microphone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in Light´J; Light Captain; EASY SHOW 2; EASY SHOW 3
Flicker-free
OLED display
For application areas such as: Clubs/dancing school; party room; stage; mobile djs / entertainer; rental
Application possibility: Suspended; on stand

Package contents

EUROLITE SB-4 Soft Bag L

Black soft bag for up to 4 devices, 320 x 320 x 200 mm

Practical transport bag offers enough space for several lighting effects and accessories
With dividers
With 2 Outside pockets
With 4 device compartments
High-quality workmanship with nylon , black, water repellent
Interior with foam padding
cover with foam padding
2 carrying straps

Package contents

Technical specifications

Weight:	3,60 kg
EUROLITE LED CAT-80 Beam Effect
Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	110 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via P-Con (blue), mounting version power supply cord with safety plug
Fuse:	5 x 20 mm, T 2 A fuse replaceable
Lamp type:	LED lamp
LED type:	1 x 80 W COB (chip-on-board) cold white (CW)
Flash rate:	0 - 25 Hz
Equipment:	Gobo wheel with static gobos; focus manual
Gobos:	Gobo wheel with static gobos, 9 color gobos and open
DMX channels:	7
DMX input:	3-pin XLR (M) mounting version
DMX output:	3-pin XLR (F) mounting version
Cooling:	Cooling fan
Control:	Stand-alone; master/slave function; sound to light via microphone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in:	Light´J; Light Captain; EASY SHOW 2; EASY SHOW 3
Projection:	Flicker-free
Housing color:	Black
Display type:	OLED display
Dimensions:	Width: 29,0 cm Depth: 18,5 cm Height: 31,5 cm
Weight:	3,08 kg
Noise classification:	Class 3 (clearly perceptible sounds)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
EUROLITE SB-4 Soft Bag L
Maximum load:	25 kg
Carrying strap:	2 pc/pcs
Material:	Nylon
Color:	Black, water repellent
Compartment dimensions:	15 cm x 15 cm x 20 cm
Inside dimensions:	31 cm x 34 cm x 20 cm
Dimensions:	Width: 32 cm Depth: 41 cm Height: 20 cm
Weight:	0,52 kg
