FUTURELIGHT Set 2x Color Mega Wave.i + Case

7 mm

7°

FUTURELIGHT Set 2x Color Mega Wave.i + Case

The article is no longer in our assortment.

No. 20000182

Print product

Product badge

Set consisting of:

2 x FUTURELIGHT Color Mega Wave.i LED Moving Bar

1 x ROADINGER Flightcase 2x Mega Wave

Features

FUTURELIGHT Color Mega Wave.i LED Moving Bar

4in1 moving head with two separately tiltable LED bars and six beams with 40 W COB LEDs

With Infinity function for unlimited PAN movement
TILT movement for each LED bar separately and steplessly adjustable
Equipped with six 40 W LEDs with RGBW colors
Upgrade via optional wireless receiver module for WDMX operation (Wireless Solution - made in Sweden)
17, 18, 20 or 39 DMX channels selectable
Each LED can be controlled individually
Narrow illumination angle
Functions: built-in programs, shutter sequences, color presets for each LED independently controllable, countless RGBW colors, dimmer, strobe effect with variable speed, sound-control, Master/Slave operation
Automatic position correction
Exact positioning via 16 bit PAN/TILT movement resolution
Random strobe effect
DMX-controlled operation or stand-alone operation with Master/Slave function
Control board with graphic LCD and foil-keyboard for adjusting the DMX-starting address, PAN/TILT reverse, reset
The scenes can be modified via the Control Board or via an external controller and loaded into the memory
Number of scenes can be changed individually
Software upload by optional accessories via DMX link
ESDC function (Easy Service Data Check) with battery-buffered control board for operation time readouts etc. (the Li-Ion battery 3.7V, AAA, 10440 is not included)
Switch-mode power supply for operation between 100 and 240 Volts
Power connection via Neutrik PowerCon jack and included power cable
Feed-through output allows to power up to 8 devices
DMX control via every standard DMX controller
6 powerful LEDs 40 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Auto position correction (feedback)
Exact positioning (16 bit resolution)
Fan effect
The device is cooled by temperature-controlled fan
Control via RDM; DMX; stand-alone; W-DMX by wireless solution; sound to light via microphone
Preprogrammed in LED PC-Control 512
Flicker-free
With a beam angle of 7°

ROADINGER Flightcase 2x Mega Wave

Trunk case with castors

Fitted for 2 devices and accessory
Additional accessory compartment
Interior upholstered with foam
High-quality workmanship with birch multiplex
Aluminum profile frames with rounded edges
Three-leg, big steel ball corners
Lid with 2 tip-over locks
2 chrome butterfly locks
4 chrome case handles
Castors
Branded hardware
For further information about this product, please refer to the Data Sheet under "Downloads"

Technical specifications

Weight:	46,90 kg
FUTURELIGHT Color Mega Wave.i LED Moving Bar
Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	200 W
IP classification:	IP20
Power connection:	Mains input via PowerCON (blue), mounting version power supply cord with safety plug (provided)
Power output:	1 x PowerCON (gray), mounting version
Lamp type:	LED lamp
LED type:	6 x 40 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Max. TILT movement:	240° exact positioning (16 bit resolution) auto position correction (feedback)
Max. PAN movement:	Exact positioning (16 bit resolution) plus infinity auto position correction (feedback)
Flash rate:	0 - 20 Hz
DMX channels:	17; 18; 20; 39
DMX input:	1 x 5-pin XLR (M) mounting version 1 x 3-pin XLR (M) mounting version
DMX output:	1 x 5-pin XLR (F) mounting version 1 x 3-pin XLR (F) mounting version
Cooling:	Temperature-controlled fan
Control:	RDM; DMX; stand-alone; W-DMX by wireless solution; sound to light via microphone
Preprogrammed in:	LED PC-Control 512
Projection:	Flicker-free
Beam angle:	7°
Beam angle (1/2 peak):	7°
Beam angle (1/10 peak):	7°
Illuminance in Lux (lx):	Red (R) 3m: 3209 lx, 6m: 1777 lx Green (G) 1m: 0 lx, 3m: 6717 lx, 6m: 2801 lx Blue (B) 3m: 820 lx, 6m: 421 lx Cold white (CW) 3m: 6993 lx, 6m: 3347 lx All 3m: 16094 lx, 6m: 7504 lx
Housing color:	Black
Dimensions:	Width: 25 cm Depth: 53,8 cm Height: 34,2 cm
Weight:	12,85 kg
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
ROADINGER Flightcase 2x Mega Wave
Maximum load:	100 kg
Transport aid:	Castors
Use of brands:	Branded hardware
Material:	Birch multiplex, 7 mm
Color:	Dark brown, laminated
Dimensions:	Width: 73 cm Depth: 62 cm Height: 55 cm
Weight:	21,20 kg
Strength:	7 mm
Outside dimensions (W x D x H):	730 x 620 x 550 mm
