Mobile column PA system with stereo Bluetooth link, 410 W
OMNITRONIC ACS-410BTS Active Column Speaker System

Mobile column PA system with stereo Bluetooth link, 410 W-MainBild

Mobile column PA system with stereo Bluetooth link, 410 W-Bild-1

Mobile column PA system with stereo Bluetooth link, 410 W

OMNITRONIC ACS-410BTS Active Column Speaker System

The article is no longer in our assortment.

No. 11038866

Print product

Product badge

Here you find the manual and downloads for
OMNITRONIC ACS-410BTS Active Column Speaker System

ACS-410BTS

The ACS-410BTS is your active column PA system for mobile applications. It consists of a powerful subwoofer speaker with 2-channel amplifier module and a full-range column speaker.

EQUIPMENT

The system has two mono inputs (XLR and jack) for microphones and line sources, a stereo input (jack and RCA) and an AUX input for portable audio devices. You can also transfer your music wirelessly from your smartphone or tablet to your speakers - simply via Bluetooth! The amplifier delivers 310 W and 100 W and is equipped with an overload limiter.

TRANSPORT

The column module can be easily mounted on the subwoofer cabinet with the supplied telescopic rod. Do you need more? No problem: The integrated stereo Bluetooth function allows two systems to be linked wirelessly..

OPERATION

Features

Mobile column PA system with stereo Bluetooth link, 410 W

Highly portable column PA system with 410 watts power
Clear, dynamic sound and wide coverage for DJs, musicians, presenters and events
Stereo Bluetooth link for wireless stereo operation with 2 systems linked together
10" bassreflex subwoofer with class D amplifiers (310 W + 100 W)
Column speaker with 6 x 2" drivers
Integrated Bluetooth audio streaming
Built-in 6-channel mixer
2 mono inputs mic/line with 2-band EQ and adjustable reverb
1 stereo line input
1 stereo AUX input connects any non-Bluetooth device
Volume control per channel
Adjustable monitor output
Master level control with limiter indication
Subwoofer with M20 threaded flange and locking features for secure transport of column speaker and distance tube
MDF enclosures with scratch-resistant lacquer surface, impact-resistant steel grille and carry handles
Total weight just 18 kg
Delivery includes variable distance tube, speaker cable and power cable
Control via Bluetooth

Package contents

1 x power cord, 1 x speaker cable, 1 x bass, 1 x top, 1 x stand, 1 x user manual

Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	400 W
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power:	Rated: 100W RMS HF Rated: 310W RMS LF
Frequency range:	45 - 20000 Hz
Control:	Bluetooth
Connections:	Output: speaker via speaker built-in socket (F) Output: line via RCA (F) mounting version Input: line via 1 x stereo RCA Input: line via 2 x 6.3 mm jack socket (stereo) mounting version Input: mic/line via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version) Input: AUX via 1 x 3.5 mm jack (stereo) mounting version
Input channels:	2 x stereo with mic-line switch via Combination socket (XLR/jack), channel control via rotary dial 1 x stereo via jack, channel control via rotary dial 1 x stereo via RCA or jack plug, channel control via rotary dial
Crossover frequency:	220 Hz
Speaker:	1 x woofer 10" 6 x tweeter 2"
Dimensions:	Width: 33,5 cm Depth: 41 cm Height: 57 cm
Weight:	18,10 kg
