Compact stereo mixing amplifier, 2 x 300 W / 4 ohms
OMNITRONIC DJP-700 Class D Amplifier

The article is no longer in our assortment.

No. 10451601

Features

Compact stereo mixing amplifier, 2 x 300 W / 4 ohms

For quick-access music playback control in restaurants, fitness studios and retail locations
Efficient class D circuitry
Silent operation due to fanless cooling concept
Extremely low weight and height due to integrated switch mode power supply
2 operating modes can be selected (stereo or bridged)
Speaker switch-on delay and auto limiters
4 stereo line inputs
1 mono microphone input with gain control on the front panel
Additional 3.5 mm connection on the front panel
Audio source selector
Controls for volume, bass and treble
Stereo master output
Extensive protective circuits
Robust steel chassis with aluminum front panel

Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	130 W 1/8 power
Output power:	2 x 200 W RMS (8 ohms) 2 x 300 W RMS (4 ohms)
Circuitry:	Class D
Equalizer:	Master: 1 x 2-band tone control stereo
Dimensions:	Width: 25,6 cm Depth: 23,3 cm Height: 4,45 cm
Weight:	2,36 kg
Power output sine:
stereo 4 ohms	2 x 300 W
stereo 8 ohms	2 x 200 W
8 ohms bridged	1 x 600 W
Frequency range:	20-20000 Hz, ±0.5 dB
Damping factor:	>300
Distortion factor:	0.05 %
Slew rate:	14 V/µsec
S/N ratio:	100 dB
Input impedance:	20 kohms (balanced), 10 kohms (unbalanced)
Input sensitivity:	1 V
Input connectors:
Line 1-4:	RCA L/R
Mic:	combination XLR/6.3 mm jack, unbal.
Aux:	3.5 stereo jack
Output connectors:
Master:	RCA L/R
Speaker:	screw connectors
Circuitry:	class D
Control elements:	power switch, source selector, level/tone controls, mode switch (stereo/bridged)
LED indicators:	power
Protection circuits:	softstart, short-circuit, overheat, clipping, overload, VHF signals, DC voltage
Construction:	steel chassis, aluminum front
Dimensions (DxWxH):	256 x 233 x 44 mm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397563306	2,76 kg	33,5cm x 28,5cm x 8cm
10	4026397563511	28,30 kg	69cm x 30,5cm x 42cm
