Technical specifications

Power supply:	230 V AC, 50 Hz
Output power:	650 W RMS (8 ohms)
Circuitry:	Class AB
Housing design:	(19") 48.3 cm rack installation
Dimensions:	Width: 48.3 cm Depth: 42.5 cm Height: 8.9 cm
Weight:	16.00 kg
Power consumption:	1700 W (1/8 power)
Power output sine:
Stereo 4 ohms	2 x 1000 W
Stereo 8 ohms	2 x 650 W
8 ohms bridged	1 x 2000 W
Frequency range:	10-50000 Hz, ±1.5 dB
Damping factor:	>250
Distortion factor:	0.1 %
Slew rate:	30 V/µsec
S/N ratio:	>90 dB
Input sensitivity:	0.77 V/1.0 V/1.4 V
Input impedance:	20 kohms
Input voltage:	max. 21 dBV/9V
Input connectors:	2 x XLR, 6.3 mm jack
Output connectors:	2 x Speaker, 1 x Speaker (bridge), 2 x pairs of screw terminals
Control elements:	power switch, level control per channel, mode switch, limiter switch, groundlift switch, input sensitivity switch
Protection circuits:	short-circuit, overheat, DC voltage, power on/off transients, softstart
Construction:	steel chassis with aluminum front panel
Dimensions (DxWxH):	425 x 482 x 106 mm (19", 2 U)

Packaging units

PU	EAN	Weight	Dimensions
1	4026397537956	17,00 kg	52cm x 47cm x 18cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
10451069-Images-.zip

OMNITRONIC E-2000 MK2 Amplifier

The article is no longer in our assortment.

Check out the alternatives:

No. 10451069

Stereo PA amplifier with limiter

Class AB circuitry
3 operating modes can be selected (stereo, parallel bridged)
Limiter, switchable
Speaker switch-on delay
2 level controls
Each channel with LED for activated protective circuit (protect) and 7-fold output meter with clip LED
Complete protection set against short-circuit, overheat, DC voltage, power on/off transients
Groundlift switch against humming
Selectable input sensitivity
Fan cooling
Speaker outputs via lockable Speaker jacks and pairs of screw terminals
Signal inputs via XLR or 6.3 mm mounting jacks
Additional Speaker plug for 8-ohm bridge operation
8-ohm bridge operation via screw terminals or additional Speaker plug
Rack installation
(19") 48.3 cm rack installation
