4-channel rotary mixer with 3-band frequency isolator for DJs
OMNITRONIC TRM-402 4-channel Rotary Mixer

Name: OMNITRONIC TRM-402 4-channel Rotary Mixer
Brand: OMNITRONIC
SKU: 10355930
Price: 499.00 EUR
Availability: InStock

4-channel rotary mixer with 3-band frequency isolator for DJs-MainBild

4-channel rotary mixer with 3-band frequency isolator for DJs-Bild-1

4-channel rotary mixer with 3-band frequency isolator for DJs

OMNITRONIC TRM-402 4-channel Rotary Mixer

Stock for approx. 12 wk(s)

499,00 €

Save money: This article is available in a bundle.

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 10355930

Print product

Product badge

Here you find the manual and downloads for
OMNITRONIC TRM-402 4-channel Rotary Mixer

TRM-402 4-Kanal Rotary Mixer

Retro fun with 4 channels

The 2-channel version of this mixer, the TRM-202 MK3 from Omnitronic, was particularly popular with DJs of electronic music all over the world. With the TRM-402 4-channel rotary mixer, the popular concept is extended by 2 channels: Now nothing hinders a creative 4-deck DJ set or a flying change during a gig. Of course, this version also incorporates the classic features of a rotary mixer in the form of ALPS rotary controls (Blue Velvet RK27) and a 3-band frequency isolator.

Smooth transitions

The high-quality components of the TRM-402 ensure an appealing sound image. The large rotary knobs of the 4 channels allow the DJ to create very smooth transitions, which are so difficult to set with a conventional mixer (with faders). All channels can be switched between line & phono inputs or sources. A microphone input is also available. The kill characteristic of the isolator ensures the complete elimination of bass, midrange and treble and thus creative mixing.

Recording your own set

The TRM-402 is equipped with a booth output and a separate volume control. So the use of the mixer in the club is no problem at all. Thanks to the record out, it is also possible to record your own DJ set.

Woodkits made in Italy

Andrea Bano a.k.a DJ Baxx from Italy produces with his company Omni custom-made woodkits for our TRM-202MK3 2-channel rotary mixer. In his online shop you can choose between seven different kits.

All woodkits and further information about the product can be found here:

Discover now

Save money: This article is available in a bundle.

Sets are loaded. Please wait...

Features

4-channel rotary mixer with 3-band frequency isolator for DJs

Classic rotary mixer with 4 input channels and integrated 3-band frequency isolator for DJs
Gain control, 2-way equalizer (highs/lows) and phono/line switching per channel
Dedicated boost and kill cut
Kill cut feature allows DJs to completely remove low, mid and high frequencies for amazing mixing
Classic ALPS potentiometers (Blue Velvet RK27)
High-grade components ensure long life and excellent sound quality
DJ microphone input with separate level control
Prefader listening to input channels and the master output via adjustable headphones output, with cue mix/split function
12-digit stereo LED level meter and master level control
Booth output with separate level control
Dual inputs for DJ microphone and headphones on the top and front panel
Outputs: master and booth (XLR/RCA L/R), record (stereo RCA)
Desktop console housing
For application areas such as: Clubs/dancing school; mobile use; mobile djs / entertainer; homerecording and studios

Package contents

1 x device, 1 x power cord, 1 x user manual

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	7,2 W
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Frequency range:	20 - 20000 Hz microphone 20 - 20000 Hz line 40 - 18000 Hz phono
S/N ratio:	>77 dB phono >80 dB microphone >85 dB line
THD:	Line <0,03 % at 1 kHz Phono <0,1 % at 1 kHz
Gain:	Microphone 44 dB Line 20 dB Phono 60 dB to +75 dB
Isolators:	Master Gain:- ∞ bis +9 Low/mid 300 Hz, 18db/oct , Butterworth Mid/high 4000 Hz, 18db/oct , Butterworth
Control elements:	Power switch, source selector, cue mix split function, tone control
Status LED:	Power, master level meter, chanal source, CUE, microphone
Connections:	Input: line via 4 x stereo RCA Input: line/phono via 4 x stereo RCA Input: microphone via 2 x 3-pin XLR Output: headphones via 2 x 6.3 mm jack socket (stereo) mounting version Output: headphones via 2 x 3.5 mm jack (stereo) mounting version Output: rec. via 1 x stereo RCA Output: booth via 2 x 3-pin XLR Output: booth via 1 x stereo RCA Output: master via 2 x 3-pin XLR Output: master via 1 x stereo RCA
Channels:	Input chanel: 4 x stereo with line-line/phono switch via RCA, channel control via rotary, 2-band tone control EQ, gain control, phono gain rotary, CUE switch, source selector Microphon chanal: 1 x mono via XLR, channel control via rotary dial, ON AIR switch Booth output: 1 x stereo via XLR or RCA, channel control via rotary dial Master output: 1 x stereo via XLR or RCA, channel control via rotary dial Headphones output: 1 x stereo via jack, channel control via rotary dial, cue mix split function
Max. level:	Output: +22 dBu
Material:	Metal
Color:	Black
Housing design:	Desktop console housing
Dimensions:	Width: 33 cm Depth: 24,7 cm Height: 10,7 cm
Weight:	4,05 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397659948	4,60 kg	42,5cm x 29,5cm x 14,5cm
4	4026397659955	19,00 kg	59cm x 44,5cm x 33cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

IC NJM 4580 M SMD CFL-1642

Capacitor 10µF 50V

Button (potentiometer) ISO-23D DJ-Isolator black inside silver Ø=26,5mm medium

More 24 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
