2-channel rotary mixer with 3-band frequency isolator for DJs
OMNITRONIC TRM-202MK3 2-channel Rotary Mixer

Name: OMNITRONIC TRM-202MK3 2-channel Rotary Mixer
Brand: OMNITRONIC
SKU: 10355922
Price: 349.00 EUR
Availability: OutOfStock

2-channel rotary mixer with 3-band frequency isolator for DJs-MainBild

2-channel rotary mixer with 3-band frequency isolator for DJs-Bild-1

2-channel rotary mixer with 3-band frequency isolator for DJs

OMNITRONIC TRM-202MK3 2-channel Rotary Mixer

available in approx. 7 wk(s)

Available alternatives

OMNITRONIC TRM-402 4-channel Rotary Mixer

OMNITRONIC TRM-422 4-channel Rotary Mixer

349,00 €

Save money: This article is available in a bundle.

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 10355922

Print product

Product badge

Here you find the manual and downloads for
OMNITRONIC TRM-202MK3 2-channel Rotary Mixer

TRM-202MK3 ROTARY MIXER

Back to the roots

For some time now, rotary mixers have been making a big comeback in the world of electronic dance music. The TRM-202 MK3 from Omnitronic offers the DJ all the classic features of a rotary mixer with its ALPS knobs (Blue Velvet RK27) and the built-in 3-band frequency isolator.

Smooth transitions

The high-quality components provide a good and appealing sound. The large knobs of both channels allow very smooth transitions, which are difficult to set with a conventional mixer (with faders). For both channels, you can switch between 2 x line & phono inputs or sources. A microphone input is also available. The isolator's kill characteristics completely eliminate bass, midrange, and treble for creative mixing.

Recording your own set

Due to the booth output and a separate volume control, the use of the TRM-202 MK3 in the club is no problem. Thanks to the record output, it is also possible to record your own DJ set.

Save money: This article is available in a bundle.

Sets are loaded. Please wait...

Features

2-channel rotary mixer with 3-band frequency isolator for DJs

Classic rotary mixer with 2 input channels and integrated 3-band frequency isolator for DJs
Gain control, 2-way equalizer (highs/lows) and phono/line switching per channel
Dedicated boost and kill cut
Kill cut feature allows DJs to completely remove low, mid and high frequencies for amazing mixing
Classic ALPS potentiometers (Blue Velvet RK27)
High-grade components ensure long life and excellent sound quality
DJ microphone input with separate level control
Prefader listening to input channels and the master output via adjustable headphones output, with cue mix/split function
12-digit stereo LED level meter and master level control
Booth output with separate level control
Outputs: master and booth (XLR/RCA L/R), record (stereo RCA)
Desktop console housing
For application areas such as: Clubs/dancing school; mobile use; mobile djs / entertainer; homerecording and studios

Package contents

1 x device, 1 x power cord, 1 x user manual

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	6,5 W
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Frequency range:	20 - 20000 Hz microphone 20 - 20000 Hz line 40 - 18000 Hz phono
S/N ratio:	>77 dB phono >80 dB microphone >85 dB line
THD:	Line <0,03 % at 1 kHz Phono <0,1 % at 1 kHz
Gain:	Microphone 44 dB Line 20 dB Phono 60 dB to +75 dB
Isolators:	Master Gain:- ∞ bis +9 Low/mid 300 Hz, 18db/oct , Butterworth Mid/high 4000 Hz, 18db/oct , Butterworth
Control elements:	Power switch, source selector, crossfader, cue mix split function, tone control
Status LED:	Power, master level meter, chanal source, CUE, microphone
Connections:	Input: line via 2 x stereo RCA Input: line/phono via 2 x stereo RCA Input: microphone via 1 x 3-pin XLR Output: headphones via 1 x 6.3 mm jack socket (stereo) mounting version Output: rec. via 1 x stereo RCA Output: booth via 2 x 3-pin XLR Output: booth via 1 x stereo RCA Output: master via 2 x 3-pin XLR Output: master via 1 x stereo RCA
Channels:	Input chanel: 2 x stereo with line-line/phono switch via RCA, channel control via rotary, 2-band tone control EQ, CUE switch, phono gain rotary, source selector Microphon chanal: 1 x mono via XLR, channel control via rotary dial, ON AIR switch Booth output: 1 x stereo via XLR or RCA, channel control via rotary dial Master output: 1 x stereo via XLR or RCA, channel control via rotary dial Headphones output: 1 x stereo via jack, channel control via rotary dial, cue mix split function
Max. level:	Output: +22 dBu
Material:	Metal
Color:	Black
Housing design:	Desktop console housing
Dimensions:	Width: 19 cm Depth: 25 cm Height: 10,7 cm
Weight:	2,68 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397659962	3,18 kg	14cm x 25cm x 32cm
4	4026397659979	13,70 kg	59cm x 35cm x 29cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Capacitor 10µF 50V

Button (potentiometer) ISO-23D DJ-Isolator black inside silver Ø=26,5mm medium

Button (potentiometer) TRM-202MK3 black inside silver Ø=22,5mm small

More 31 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
