1-channel DI box, active
OMNITRONIC LH-065 DI Box active

Name: OMNITRONIC LH-065 DI Box active
Brand: OMNITRONIC
SKU: 10355065
Price: 69.90 EUR
Availability: InStock

Stock for approx. 12 wk(s)

69,90 €

58,74 €

-16% valid until 31.01.2025

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

Item no. 10355065

Features

1-channel DI box, active

1 high-impedance signal input via XLR or 6.3 mm jack connectors
1 low-impedance XLR output
6.35 mm jack input, and output
Converts an unbalanced line input (e.g. instruments) into a balanced XLR output for connecting a mixer
Switchable input attenuation: 0 dB, -20 dB, -40 dB
Cables can be routed under the housing
For application areas such as: Installation; mobile use; mobile djs / entertainer

Package contents

Technical specifications

Protection class:	Protection class III
Power connection:	Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Battery:	1 x 9.0 V E block 6F22 zinc carbon included
Frequency range:	10 - 30000 Hz
THD:	<0,5 % at 1 kHz
Impedance:	Input: 470 kOhm Output: 600 Ohm
Input attenuation:	0 dB, -20 dB, -40 dB; switchable
Housing color:	Silver
Control elements:	Power switch, groundlift selector, Input sensitivity switch
Connections:	Input: 1 x 3-pin XLR Input: 1 x 6.3 mm plug (unbal.) Link: 1 x 6.3 mm plug (unbal.) Output: line via 1 x 3-pin XLR
Max. level:	Output: +6 dBu
Dimensions:	Width: 15 cm Depth: 13 cm Height: 6 cm
Weight:	540 g

Packaging units

PU	EAN	Weight	Dimensions
1	4026397194913	0,75 kg	23,5cm x 16cm x 9,5cm
12	4026397194920	9,75 kg	49cm x 49cm x 21cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

No spare parts available.

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/Produktanfrage

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
