6-channel microphone/line mixer
OMNITRONIC EM-260B Entertainment Mixer

Name: OMNITRONIC EM-260B Entertainment Mixer
Brand: OMNITRONIC
SKU: 10007076
Price: 199.00 EUR
Availability: InStock

6-channel microphone/line mixer-MainBild

1 U

6-channel microphone/line mixer

OMNITRONIC EM-260B Entertainment Mixer

Stock for approx. 12 wk(s)

199,00 €

Find a dealer

List price excl. 19% VAT
Prices in retail stores may vary.

No. 10007076

Print product

Product badge

Here you find the manual and downloads for
OMNITRONIC EM-260B Entertainment Mixer

Mixer for microphone and line sources

The perfect tool for your karaoke party: With the Omnitronic EM-260B Entertainment Mixer you mix 3 microphone and 3 line sources to one stereo output - in an very simple way. Installing the mixer is easy as well, thanks to the small dimensions you are flexible.

Design clearly arranged

Even if you are a beginner, you can operate the mixer very easily. As it is clearly structured, you won't get lost. Each channel has a clip LED. The microphone inputs show optional 12 V phantom power. The unit is perfectly suited for bar, restaurant or club house installation.

Effects an recording sessions

With the FX send/return (with FX level control) you can cut in effects to support your voice. Record singing sessions by using the record output.

Features

6-channel microphone/line mixer

6 inputs (3 x mic/line and 3 x line) for mixing to 1 stereo output
Ideal e.g. for karaoke when microphones need to mixed with CDs
3 mono input channels mic/line (XLR, bal.), switchable
3 stereo line input channels (RCA)
Clip LED for each microphone channel
Each microphone input with optional 12 V phantom power
FX send/return with FX level control
Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
Stereo record output (RCA)
(19") 48.3 cm rack installation 1 U
For application areas such as: Installation; restaurants, bars and hotels; clubs/dancing school

Package contents

1 x device, 1 x power cord, 1 x user manual

Technical specifications

Power supply:	115/230 V AC, 50/60 Hz
Power consumption:	5 W
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Frequency range:	20 - 20000 Hz
Phantom power:	Or 12 V DC
Housing color:	Black
Control elements:	Phantom power switch, power switch, FX send/returne control
Status LED:	Power, clip
Connections:	Input: mic/line via 3 x 3-pin XLR Input: line via 3 x stereo RCA Input: FX via 2 x 6.3 mm jack socket (mono) mounting version Output: rec. via 1 x stereo RCA Output: master via 2 x 6.3 mm jack socket (mono) mounting version Output: FX via 1 x 6.3 mm jack socket (stereo) mounting version
Channels:	Input chanel: 3 x stereo via RCA, channel control via rotary dial, 2-band tone control EQ 100Hz/10kHz Microphon chanal: 3 x mono with mic-line switch via XLR, channel control via rotary dial Master output: 1 x stereo via jack, channel control via rotary dial
Max. level:	Input: microphone +14 dB Input: line +24 dB
Material:	Metal
Housing design:	(19") 48.3 cm rack installation 1 U
Dimensions:	Width: 48,3 cm Depth: 12,3 cm Height: 4,45 cm
Weight:	2,30 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397357981	2,65 kg	53,5cm x 27cm x 9cm
4	4026397357998	11,70 kg	55,5cm x 55,5cm x 20,5cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Transformer Sec.: 19-0-19V Pri.: 230V (EI-41*26) GEQ-215

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support

Safety instructions and warnings

Specific safety instructions that apply to the product can be found in the operating instructions for the product.
