Intusonic News

Slim column for the middle distance

The 4VM100T by INTUSONIC is a versatile column speaker specially designed for multimedia applications. With its precise sound dispersion, unwanted reflections from ceilings and floors are avoided, while a wide horizontal coverage is guaranteed. Thanks to customized waveguides and phase plugs, this speaker is perfect for medium distances, and ideal for seated listeners in classrooms, lecture halls, chapels, and conference rooms.

Inside the speaker are four 4-inch woofers with phase plugs in a closed housing and four 1-inch silk dome tweeters in a 5° downward-facing waveguide. This combination ensures focused vertical and wide horizontal dispersion, which enables optimum sound distribution. The passive crossover guarantees the best possible sound quality.
For the connecting options, the speaker offers dual parallel Speakon-compatible connections as well as a 5.0 mm 4-pin screw terminal connection (2x2 parallel). Various mounting options are available: 75 mm VESA mount (rear), one M10 mounting point (top) and three M6 mounting points as well as two slotted mounting plates for flush wall mounting.

The speaker‘s housing is made of 12 mm MDF and has a textured, scratch-resistant black or white paint finish. A robust steel front grille with foam on the back reliably protects the speaker components.
The 4VM100T offers high-quality, reliable audio quality and is perfect for a variety of applications where precise sound dispersion and flexible mounting options are required: whether in classrooms, chapels, or conference rooms.

Athletic media player

The INTUSONIC PAA42+ is a versatile media preamp/mixer that offers a wide range of functions for professional audio applications. It combines a 6-channel stereo preamplifier with two microphone inputs and an integrated media player. Particularly noteworthy is the combination of phantom power and high-pass filters in the microphone section and the automatic attenuation of the music signal (talk over/priority), which is ideal for fitness trainers in sport courses and similar applications. The integrated media player supports USB playback, FM reception, the LINKOUSTIC™ 5.0 Wireless Audio Link, and an IR remote control. A DAB+ receiver provides additional music enjoyment.

The amplifier offers three unbalanced stereo line inputs (RCA) and one balanced stereo input (1/4‘‘ FOH input) with gain control and an unbalanced 3.5 mm jack stereo input on the front. Two balanced microphone inputs with 3.5 mm screw terminals at the rear and an additional 1/4‘‘ TRS socket for a second microphone at the front offer flexible connection options. The microphone inputs have gain controls, switchable phantom power (12V), high-pass filter as well as a 2-band EQ, volume control, on-air switch, and adjustable talkover.

The media player supports USB playback with access to files and folders, has a 128x64 LCD display, regular/random playback, FM/RDS tuner mode, and a 4-jingle player with scheduled playback modes. The player is supplied with an IR remote control.
The amplifier has two master outputs with an evacuation function, which can operate in mono or stereo. It also offers an emergency input function that replaces the master signal with an emergency signal at an adjustable level. The INTUSONIC PAA42+ is an excellent amplifier for a wide range of applications where high audio quality, versatility, and ease of use are crucial, for example, in gyms, schools, or conference rooms.

Keep the overview

The INTUSONIC HMA72 and HMA74 zone distributors each form the heart of INTUSONIC’s digitally controlled audio zone and paging system. Together with the HZE11 zone remote control wall panel and the HPA41 paging station, a flexible and scalable system for background music and announcements is quickly created. These zone distributors offer a variety of inputs, including four unbalanced stereo line inputs (RCA) and one balanced stereo input (1/4’’ FOH input), each with gain control. An unbalanced 3.5 mm jack stereo input on the front provides additional flexibility.

Two balanced microphone inputs on 3.5 mm screw terminal inputs are equipped with gain controls on the front and a phantom power switch on the rear. The two or four-zone outputs can be flexibly configured and offer mono switches, 100 Hz high-pass filters, maximum level control, 2-band EQ and adjustable volumes for announcements and emergencies. The zones can be conveniently controlled via the 2x8 LCD display, the encoder, or the IR remote control.
For emergencies, both the HMA72 and the HMA74 have an input that replaces the master signal with an emergency signal and an output muting circuit. The robust metal housing with removable handles ensures a long service life and easy installation.

Accessories

The HZE11 zone remote wall panel allows remote control of all zone settings and enables local audio feed. It is powered by the HMA72 via a Cat5 cable and offers the same zone settings as the main unit.
